In Dunedin, the ground doesn't always show its hand. We've logged dozens of sites across South Dunedin and the Taieri Plain where clean-looking sands turn problematic fast under cyclic loading. The city sits on a mix of Holocene alluvium, estuarine silts, and dune sands — materials that the NZGS guidelines flag for high liquefaction susceptibility when groundwater is shallower than 3 metres. Our team runs field testing with CPT rigs and SPT hammers, then backs it up with lab cyclic triaxial on Shelby tube samples. For sites near the harbour edge we often pair the liquefaction assessment with a seismic microzonation study to map lateral spreading hazard across the property footprint. The 1974 Dunedin earthquake only reached M5, but the Akatore Fault can generate much larger events — and the loose dredged fills underlying the flat suburbs won't behave kindly when it does.
Loose saturated sands in Dunedin's reclaimed flats can lose 60% of their bearing capacity in 15 seconds of strong shaking — and the water table determines exactly where.
Methodology applied in Dunedin
Local geotechnical conditions in Dunedin
Dunedin's climate adds a layer of complexity that drier regions don't face. The city gets over 800 mm of rain annually, and the basalt caprock of the Otago Peninsula funnels groundwater into the coastal flats. A soil profile that drains in February can be fully saturated by July — and saturation is the trigger for liquefaction. We've seen sites where the factor of safety drops from 1.4 to 0.9 just because the winter water table rises 400 mm. That's the difference between no ground improvement and needing stone columns across the entire pad. The Akatore Fault, 40 km southwest of the CBD, last ruptured around 1300 AD with an estimated M7+ event. A repeat would produce PGA values exceeding 0.25g at the harbour basin. Combined with the 10-15 metre thickness of liquefiable material we've mapped in cores from the Kaikorai Estuary, the settlement estimates run 150-250 mm — differential, not uniform. That's what breaks services and tilts floor slabs.
Our services
Our Dunedin-based work covers the full investigation-to-mitigation chain. We don't just calculate factors of safety and walk away — we stay involved through the design phase to make sure the numbers translate into buildable solutions:
CPTu liquefaction screening
Continuous cone penetration testing with pore pressure measurement to map liquefiable layers at 20 mm resolution. We process data through CLiq or custom Python scripts, delivering Ic profiles, CRR curves, and FSL colour logs keyed to NZS 1170.5 site subsoil classes.
Cyclic triaxial laboratory program
Undisturbed sampling with thin-wall Shelby tubes or Osterberg piston sampler, then stress-controlled cyclic triaxial at our IANZ-accredited lab. We test at multiple confining pressures and CSR levels to build site-specific liquefaction resistance curves rather than relying solely on empirical correlations.
Liquefaction mitigation design
From vibro-replacement stone columns to rigid inclusions and deep soil mixing grids. We prepare performance specifications, QA/QC testing plans, and post-treatment verification using pre- and post-improvement CPT comparisons with statistical analysis of improvement ratios by depth.
Common questions
How much does a soil liquefaction analysis cost for a residential section in Dunedin?
For a standard residential lot in Dunedin, budget between NZ$4.100 and NZ$6.600. The spread depends on access for the CPT rig, number of test locations, and whether we need to run cyclic triaxial on undisturbed samples. Sites in South Dunedin with very soft surface soils sometimes need push platforms, which sits at the upper end of the range. We'll give you a fixed quote after reviewing the property location and any existing geotechnical data.
Do I need a liquefaction study if my property is on the Dunedin hills?
Generally not for the hill suburbs themselves — the residual soils and weathered schist bedrock on the slopes around Maori Hill or Roslyn have negligible liquefaction potential. But if your property includes a flat bench of colluvium or a spring-fed area with perched groundwater, we'd recommend at least a screening-level assessment. The boundary between 'hill' and 'flat' isn't always clean, and localised saturation can surprise you.
What's the difference between CPT and SPT for liquefaction assessment?
CPT gives us a near-continuous profile — every 20 mm — with direct measurement of tip resistance, sleeve friction, and pore pressure. That lets us pick out thin liquefiable seams that SPT would miss entirely. SPT recovers a sample we can describe and test for fines content. In Dunedin's interbedded sands and silts, we use CPT as the primary tool and calibrate with a few SPTs where the soil behaviour type index is ambiguous. The NZGS Module 1 guidelines accept both methods, but the correlations are more solid from CPT data for the soils we encounter here.
How long does the analysis take from site work to final report?
Fieldwork is usually one day for a single-family residential site. The lab program — if we're running cyclic triaxial — takes 3-4 weeks because the tests themselves run for hours each and we need to consolidate specimens to in-situ stress first. Desktop analysis and reporting add another week. So figure 5 weeks total if lab testing is required, or 2 weeks for a CPT-only screening report. We can fast-track the screening to 5 working days for urgent purchase conditions.
